TLS ClientHello fingerprint gate that reduces scanner noise ahead of TLS services.

GitHub repository

Source: README.md
Commit: e309257dd1138f3355cff3dbd2c5c08ef6162708
Source updated:  ·  Edit this page

tlsgate mark
Porter mascot for the gate tools

Written with AI. This project was developed with the help of an AI assistant (Anthropic's Claude, via Claude Code). The code has been reviewed and tested, but treat it accordingly: read it before you run it, and see the security model below for what it does and does not protect.

tlsgate is a TCP proxy that fingerprints TLS ClientHellos with JA3 or JA4 and allows or blocks connections using an approval store. Routes are generic; fronting mail submission and retrieval ports is the common case.

It can run standalone or report observations to Gatehub, the shared control plane for the *gate tools.

https://github.com/user-attachments/assets/16ee363c-249f-4c97-a35c-2d30159c9f01

How it works

tlsgate sits in front of one or more TLS backends and reads the ClientHello before forwarding traffic. Unknown fingerprints are blocked by default. During enrollment, --allow-unknown records new fingerprints as pending while allowing them through; remove it after approving known clients.

client ──► tlsgate ── approved fingerprint ──► TLS backend
                    └─ unknown or blocked ───► drop

The proxy does not terminate TLS. Approved traffic continues to the real backend unchanged.

Security model

A TLS fingerprint is not a credential. JA3 and JA4 are trivially spoofable.

Treat this as a noise filter against opportunistic scanners and generic credential-stuffing traffic, not as authentication or access control. The real security boundary remains the backend's TLS termination, authentication, rate-limiting, and abuse controls. Do not weaken backend security because tlsgate is present.

The proxy also enforces per-source and global connection limits and bounds fingerprint-store growth. Those controls reduce resource abuse but do not make fingerprints identities.

JA3 or JA4

Use --fingerprint ja3 (the default) or --fingerprint ja4.

  • JA3 is order-sensitive and has a large public corpus, but clients that shuffle TLS extensions can produce unstable fingerprints.
  • JA4 sorts ciphers and extensions before hashing, making it more stable for a small self-seeded allowlist.

The database records which method created its keys. Starting with a different method fails rather than silently invalidating existing decisions. Switching methods requires an explicit reset and re-enrollment.

Quick start

Download a static Linux binary from the GitHub releases page, or build and test with Go 1.27.1 or newer:

go build -o tlsgate .
go test ./...

Use an unprivileged high port for a temporary enrollment window, leaving the real public listener untouched while you test:

./tlsgate serve \
  --route '[::]:1993=127.0.0.1:10993' \
  --db ./tlsgate.db \
  --fingerprint ja4 \
  --allow-unknown

After connecting known clients, review and approve their fingerprints:

./tlsgate list -v --db ./tlsgate.db
./tlsgate approve --db ./tlsgate.db --label "Alice phone" <fingerprint>

Remove --allow-unknown for normal operation.

Validate the same startup inputs without opening the database, connecting to a backend, or binding a port:

./tlsgate doctor \
  --route '[::]:1993=127.0.0.1:10993' \
  --db ./tlsgate.db \
  --fingerprint ja4

Deployment

The included Ansible playbook is the primary deployment path:

cd ansible
cp inventory.example inventory
cp group_vars/tlsgate.example.yml group_vars/tlsgate.yml
# Edit both local files for your deployment.
ansible-playbook --syntax-check playbook.yml
ansible-playbook playbook.yml --ask-become-pass

The real inventory and group variables are ignored so deployment-specific host names, network ranges, fingerprints, and notification credentials are not committed accidentally.

The backend must first move from its public port to an internal-only port. Deployment changes on an inline proxy need graceful handoff so active connections are not dropped.

See deployment for Ansible variables, graceful upgrades, Docker, and PROXY protocol configuration.

Documentation

License

MIT. See LICENSE.
