application

Gatehub

active

Shared control plane for fingerprint-gating proxies and their narrowly scoped node synchronization.

GitHub repository

Source: README.md
Commit: 0f07a57e4ba3721f23cb629e32ee325c7146ecc4
Source updated:  ·  Edit this page

Porter mascot

Written with AI. This project was developed with the help of an AI assistant (OpenAI's GPT-5, via Codex). The code has been reviewed and tested, but treat it accordingly: read it before you run it.

Gatehub is the shared control plane for TLSGate and SSHGate fingerprint observations and approval decisions. It also accepts privacy-bounded HTTP scanner signals from GateSignal and correlates them with recent TLS sightings.

It exposes two separate HTTP surfaces:

  • An internal admin UI/API for registering nodes and approving, blocking, or labeling fingerprints.
  • A narrowly scoped synchronization API for gate instances, authenticated with node credentials or mTLS.

Do not expose the admin listener as the public synchronization surface.

Security boundary

Gatehub authenticates administrators and registered nodes; it does not authenticate end users of the services behind a gate. Fingerprints and scanner signals are operator evidence, not identities. TLSGate and SSHGate remain noise filters in front of backends that must keep their own TLS, SSH, account, rate-limit, and abuse controls.

Keep the OIDC-protected admin listener separate from the node synchronization listener. A registered node may upload observations only as its configured instance identity. Bearer tokens are stored as hashes, and mTLS identities are matched to the certificate name registered for that node. The SQLite database contains operational history, node credentials, sessions, and decisions; treat the database and its backups as secrets.

Quick start

Run an unauthenticated, loopback-only development instance:

go run . \
  --db ./gatehub.sqlite \
  --admin-listen 127.0.0.1:8081 \
  --admin-auth none

Open http://127.0.0.1:8081.

Production administration uses OpenID Connect. Register https://gatehub.example.com/api/auth/callback with the identity provider, then configure the issuer, client ID, redirect URL, and optional subject, email, or group allowlists. Gatehub refuses to start an OIDC admin listener with an incomplete configuration.

Nodes must be registered before they can synchronize. Their configured certificate identity or bearer token is bound to the instance ID they report.

Deployment

The included Ansible playbook installs Gatehub and its systemd service:

cd ansible
ansible-playbook --syntax-check playbook.yml
ansible-playbook playbook.yml

The normal topology keeps the admin listener behind an internal HTTPS reverse proxy while exposing only these synchronization paths:

POST /v1/observations/batch
POST /v1/signals/batch
GET  /v1/policy
GET  /healthz

If TLS terminates at a proxy, ensure the selected node-authentication mechanism still reaches Gatehub. A conventional HTTP reverse proxy does not forward the original client certificate automatically.

See deployment and authentication for OIDC, node registration, certificates, listener configuration, and Ansible variables.

API

Gate instances upload fingerprint observations and pull approval policy. Signal-producing nodes can submit privacy-bounded aggregate scanner evidence; the admin API correlates those signals with recent TLS sightings. An optional shadow policy explains which candidates would receive a short-lived block under configured network, signal, error-ratio, and cross-site/node thresholds. A separately gated enforcement controller can promote those findings into instance-scoped, expiring decisions. It defaults to disabled, supports an explicit canary-node allowlist, publishes an explicit pending verdict at expiry, and treats manual approvals as protection overrides.

See the synchronization API reference for request and response examples, retention behavior, and the web-candidate endpoint.

Development

go build ./...
go test ./...

Gatehub uses SQLite for durable state. Treat the live database and its credential-bearing contents as sensitive operational data.

Documentation

License

MIT. See LICENSE.
